Explosion-Proof conveyor belt vulcanizer, which is specially used in explosive gases environment, it’s also called conveyor belt vulcanizing press or belt vulcanizing press machine. It’s vulcanize equipment and tools for repairing & splicing of conveyor belt. It suits for various conveyor belt, such as EP, Rubber, Nylon, Canvas and Steel cord belt, etc.
The anti-explosion belt vulcanizer is dependable, lightweight and portable machine, which is especially suits for the underground mine place, as well as the metallurgy, mining, power plants, ports, building materials, cement, coal mine, chemical industry, etc. Heating plates are available for rectangular shape to save space under pit.
1. Vulcanization pressure: 1.0-2.0 MPa;
2. Vulcanization temperature: 145°C;
3. Difference in surface temperature of vulcanized plate: ± 5°C;
4. Heating up time ( at normal temperature to 145°C )<30 minutes;
5. Voltage: 660V 3 PHASES 50/60HZ;
6. Temperature adjustment range: 0 to 200°C;
7. Timer adjustment range: 0 to 99 minutes;
8. Temperature adjusting range: 0-200°C.
EXECUTIVE STANDARD: MT/T978-2006 EXPLOSION-PROOF BELT VULCANIZING PRESS
LBD series Explosion-proof type belt vulcanizer is OEMED by the requirements of customers, belt width from 800 mm to 3000 mm.
|
MODEL |
Belt Width |
Specification |
Heating Plate Size |
Power |
Dimension |
|
MM |
(L×W) MM |
(L×W×T) MM |
KW |
(L×W×H) MM |
|
|
LBD-650 |
650 |
650*830 |
883*820*31 |
10.80 |
1140×830×585 |
|
650*1000 |
1064*820*31 |
13.00 |
1140×1000×585 |
||
|
LBD-800 |
800 |
800*830 |
883*995*31 |
12.70 |
1320×830×585 |
|
800*1000 |
1064*995*31 |
15.40 |
1320×1000×585 |
||
|
LBD-1000 |
1000 |
1000*830 |
883*1228*31 |
15.00 |
1450×830×585 |
|
1000*1000 |
1064*1228*31 |
18.00 |
1450×1000×585 |
||
|
LBD-1200 |
1200 |
1200*830 |
883*1431*31 |
18.20 |
1700×830×750 |
|
1200*1000 |
1064*1431*31 |
22.00 |
1700×1000×750 |
||
|
LBD-1400 |
1400 |
1400*830 |
883*1653*31 |
20.60 |
1950×830×750 |
|
1400*1000 |
1064*1653*31 |
24.60 |
1950×1000×750 |
||
|
LBD-1600 |
1600 |
1600*830 |
883*1867*31 |
22.80 |
2150×830×795 |
|
1600*1000 |
1064*1867*31 |
27.20 |
2150×1000×795 |
||
|
LBD-1800 |
1800 |
1800*830 |
883*2079*31 |
25.00 |
2380×830×900 |
|
1800*1000 |
1064*2079*31 |
30.00 |
2380×1000×900 |
||
|
LBD-2000 |
2000 |
2000*830 |
883*2303*31 |
27.40 |
2620×830×980 |
|
2000*1000 |
1064*2303*31 |
33.00 |
2620×1000×980 |
||
|
LBD-2200 |
2200 |
2200*830 |
883*2478*31 |
29.80 |
2830×830×980 |
|
2200*1000 |
1064*2478*31 |
35.80 |
2830×1000×980 |
